TBS Unify Pro Nano 5G8
TBS Unify Pro Nano 5G8
MY REVIEW
This is the TBS Unify Pro Nano, which just might be the single best VTX for whoops at the time of this review. That's because it's not only the cheapest but also lightest VTX you can get right now, all while still maintaining the range and signal clarity that TBS has come to be known by. This VTX also has an extra power and ground pad that you can solder your camera to, which is extra convenient for using the popular FC's for racing today, as they often don't have dedicated camera power pads.
The one downside is that I've heard the smart audio will sometimes stop working on this VTX. This would be a dealbreaker for me except there is actually a fix. Soldering the appropriate resistor between the smart audio and ground pad on the vtx seems to completely fix this issue every time. I haven't tried this myself, so don't take it as an official recommendation, but I do know that this is what some of the top pilots are doing!
I am going to be including the necessary resistor in every order of this vtx!
There’s one more downside that I’ve come to realize and that’s that this VTX does not support pit mode. This isn’t an issue for me as I don’t personally use pit mode, and I still feel this VTX is worth it due to the price, weight and performance, but if you’re one of those people that absolutely need pit mode, this isn’t the VTX for you!
SIZE MATTERS!
As builds become smaller and the innovation surrounding brushed and brushless micro quads accelerates, the need for a high-quality VTx increases. TBS has built the smallest VTx possible, focusing purely on size! Sporting the usual Unify Pro pedigree, a newly-revised u.FL connector and the industry-standard Smart Audio support. You will be blown away with the performance in terms of range, signal clarity and signal spacing.
UNLOCKING THE VTX
SPECIFICATIONS
Input Voltage | 4.5V - 5V ONLY |
Power levels | 25mW / 50mW |
Interface | SmartAudio and capacitive button (or solder external tactile button separately - included!) |
Weight | 1.4g (incl. antenna) |
Size | 13.2mm x 14.6mm |
Antenna connector | u.FL (upgraded) |
Antenna length | 45.6mm (end to end) |
TBS Tech |
Smart Audio, Clean Switch |
INCLUDES
- 1x Unify Pro nano 5G8 VTX
- 1x button switch
- 1x TBS UNIFY PRO 5G8 Linear Antenna
- 6x 30awg silicon connection wires (2 black, 2 red, 1 white, 1 yellow)
DOWNLOADS
MANUAL
VTX Table
# vtxtable vtxtable bands 5 vtxtable channels 8 vtxtable band 1 BOSCAM_A A FACTORY 5865 5845 5825 5805 5785 5765 5745 5725 vtxtable band 2 BOSCAM_B B FACTORY 5733 5752 5771 5790 5809 5828 5847 5866 vtxtable band 3 BOSCAM_E E FACTORY 5705 5685 5665 5645 5885 5905 5925 5945 vtxtable band 4 FATSHARK F FACTORY 5740 5760 5780 5800 5820 5840 5860 5880 vtxtable band 5 RACEBAND R FACTORY 5658 5695 5732 5769 5806 5843 5880 5917 vtxtable powerlevels 2 vtxtable powervalues 0 1 vtxtable powerlabels 25 50
