Happymodel EP2 ELRS RX

Happymodel EP2 ELRS RX

Regular price $13.50 USD
Regular price $13.50 USD Sale price $13.50 USD
Sale Sold out

The lightest ELRS receiver on the market coming in at under half a gram! This thing is so light, you can easily add it to your whoop builds without worrying much about it, unlike the external receivers we had back in 2019! You'll want to make sure you keep the ceramic antenna safe (I like to mount mine under the FC with tape), but if you do that, you'll find that these external receivers are much more reliable than the internal ones. I use external ELRS receivers on most of my whoop builds because they're so light and reliable.

From Happymodel

The Happymodel 2.4GHz ELRS nano series receiver is an open source program based on ExpressLRS, we have 3 types rx module released.

The PP RX is designed by @Jye Smith from ExpressLRS development team. Its main hardware architecture is STM32L432KBU6 MCU and SX1280 RF chip. It has a built-in ceramic antenna, which is super light and small in size.

On the basis of PP RX, we have developed the Nano 2.4GHz rx of ESP8285 version named EP1 and EP2.  The RF module of EP1/EP2 is the same like PP RX and use ESP8285 MCU . So you can upgrade firmware by WIFI , that’s too simple .

Due to the low-latency and high-refresh-rate RF module, they are very comfortable for FPV race and Long Range FPV. And very suitable for Tiny whoop because of the ultra light and Nano size.

Type: ISM
SX1280IMLTRT RF Module
SMD Ceramic antenna
Frequency Range: 2400 MHz to 2500 MHz
Maximum receive refresh rate: 500Hz
Minimum receiver refresh rate: 25Hz
Working voltage: 5v
Weight: 0.44gram
Dimension: 10mm*10mm*6mm
Peak gain: 3.7dB
